| Photography |
 |
The frame has two style, we will ship style1 without specifying
|
 |
| |
 |
| |
 |
Floor Stand not include
|
| |
 |
| |
| |
| |
| Video format support |
| |
| Video Extension |
Video Format |
Coding Type |
Video Resolution |
Stream Rate |
| .Dat, .Mpg .Mpeg |
Mpg, Mpeg |
Mpeg1/Mpeg2 |
1920*1080@30p |
20Mbit/sec |
| .ts, .trp, .tp, .m2ts |
Mpeg2 -TS
H264-TS |
MPEG2 ,H.264 |
1920*1080@30p |
20Mbit/sec |
| .vob |
MPEG2 -PS |
MPEG2 |
1920*1080@30p |
20Mbit/sec |
| .mp4 |
AVI, MP4 |
MPEG4
Divx3.11,Divx 4.12, Divx5.x,Divx6, 1.00,
Xvid1.01,Xvid 1.02, Xvid1.03,
Xvid1.10-beta1/2
H.264, Xvid |
1920*1080@30p |
20Mbit/sec |
| .rm, .rmvb |
RM, RMVB |
Rm |
1920*1080@25p |
10Mbit/sec |
| .mkv |
MKV |
H.264, MPEG1,2,4 |
1920*1080@30p |
20Mbit/sec |
| .divx, .avi |
AVI(1.0, 2.0),
DMF0,1,2
|
MPEG2, MPEG4
Divx3.11,Divx4.
Divx5, Divx 6,
Xvid 1.00,
Xvid1.01,Xvid 1.02, Xvid1.03,
Xvid 1.10-beta1/2
H.264 |
1920*1080@30p |
20Mbit/sec |
| .asf, .wmv |
ASF
(Revision 01.20.03) |
VC1 |
1920*1080@30p |
20Mbit/sec |
| .ts |
ts |
AVS |
1920*1080@30p |
20Mbit/sec |
| Motion JPEG |
AVI, MOV |
JPEG |
640x480 @ 30P |
10Mbit/sec |
|
| Timer: Auto power on/off and play designated files |
 |
| Playlist allow playing designated files at designate time (256 groups max) |
 |
| |
| Auto copy/update |
 |
|
More Features
|
|
1. 16:9 Full HD 1080p Resolution Panel (1920x1080) , suppoty Dat, Mpg, mpeg，ts, trp, tp, m2ts, vob,mp4, rm, rmvb, mkv, divx, avi, Motion JPEG, asf, wmv, ts 1080P@30P video (more see chart above).
2. Auto copy/update the content through USB flahs driver.
3. Timer function: Auto power on/off then play designated files on schedule, 5 groups timers available.
4. Playlist feature: Play designated files at designated times. (256 groups max)
5. Slideshow with background music.( Photo interval time 5s/7s/10s/15s/30s/60s/90s/120s/150s adjustable.)
6. Caption function: Add/Display scrolling texts on the top/bottom of screen during playing.
7. Spot announcement: Spot announcement, insert breaking video news during or after a playing.
7. Power failure memory; Auto play the position that it last stopped. .
8. USB update function.Update playlist/files simply by inserting USB flash driver.
9. Auto copy and update playlist.
10. Metal case with security locker. Password protected.
11. Mp3 lyric display.
|
|
Frame Specification
|
|
Viewing Area
|
22 inch (diagonal) 476*268 (mm)
|
|
Screen Resolution
|
1920*1080
|
| Frame Dimension |
548*333*55 (mm) |
|
Aspect Ratio
|
16:9
|
| Contrast Ratio |
1000:1 |
| Brightness |
350 nits (cd/㎡) |
| Timer Funtion |
YES |
|
Viewing Anlge
|
170° horizontal/vertical
|
| Response time |
4 ms |
|
Memory Cards support
|
CF/SD/USB Flash drive
|
|
Image Format
|
JPEG/JPG/PNG
|
|
Video Formats
|
Dat, Mpg, mpeg，ts, trp, tp, m2ts, vob,mp4, rm, rmvb, mkv, divx, avi, Motion JPEG, asf, wmv, ts, tp, trp, t2rs, divx 1080P@30P
|
|
Audio Formats
|
MP3, Wmv
|
|
Auto Power On/Off
|
Yes
|
|
Rotation
|
90/180/270 (Captions/timt/calendar rotatble)
|
|
Inteval time
|
5s/7s/10s/15s/30s/60s/90s/120s/150s
|
|
Remote Control
|
Yes
|
|
Speaker
|
2
|
|
Wall mount
|
Yes
|
|
Input voltage
|
100-250V (US/UK/AU/EU)
|
|
Language
|
English, Chinese
|
|
Packing Weight
|
12KGS/26lbs
|
| Packing Dimension |
64mm*430mm*130mm |
|
Warranty
|
12 months by Manufacturer
|
|
Contents of Package
|
- 22 inch advertising player
- Wall bracket (1)
- Operations Manual
- A/C Adapter(100V~250V) built-in
- Remote Control
- Transport Wood case to protect the frame from transit damage.
|
